J12JF Jaw for Ferrule Terminals and Insulated Cable End(6-16mm²)

Item No. : J12JF Quick Change Crimping Jaw for Ferrule Terminals and Insulated Cable End(6-16mm²)

Suitable for
● AWG 10/8/6

● DIN 6/10/16 mm²

Confined crimp :Trapezoid-Crimp & WM-Crimp

Applicable: Terminal Block/Control Panel

For: Non-Insulated Cord End Terminals(Ferrule) / Nylon-Cord End Terminals(Ferrule) / Twin Cord End Terminals(Ferrule)
DESIGNED FOR FERRULE TERMINALS - This crimping jaw will make clean trapezoid shaped crimps for ferrule wire ends 10/8/6 AWG.
These jaws are not compatible with the fixed jaw crimping tools.

Compatible with LiCrim Quick Change crimper frames system as below:

●Made in TAIWAN-More LiCrim Crimper Single Function : Please Press the button "Download" to get it.

Material: AISI- 4140
Procedure: Precision and Wax-lost Casting
Treatment: Finished with heat treatment
Surface treatment : Zinc Phosphate

AISI 4140 is a chromium-molybdenum alloy steel. The chromium content provides good hardness penetration, and the molybdenum content ensures uniform hardness and high strength. The jaws are heat treated and have a zinc phosphate surface treatment
Designed by Germany, Made in Taiwan.

COMPATIBILITY - Individual crimping jaws will work with our crimping tools with quick change locking mechanism.
No tools required. The jaws can be replaced in 5 seconds. Slide in, slide out. Patented in USA, Germany, China, Taiwan

Packing List: 120/240/CTN/18.1/19.1/KGS/1.2'
Sliding Card
Sliding Card Size: 11.3 x 8.3 x 1.5 cm
Unit Weight: 75.6g
